Wholesale Blue-white Pre Filter Media Manufacturer, Factory

Â Blue-white Pre Filter MediaÂ is critical components in heating, ventilation and air conditioning (HVAC) systems and are the first line of defense in the air filtration process. They play a vital role in improving indoor air quality by capturing larger particles such as dust, pollen and pet dander. This prevents these contaminants from entering more advanced filtration systems, protecting more delicate and expensive downstream filters.

Send Inquiry

Product Description

Main Benefits

Sustains the life of the main filter: By capturing larger particles, the air pre-filter helps extend the life of the main filter, reducing the frequency of replacement and lowering maintenance costs.

Improves air filtration: Ensures only purer air flows through the main filter, improving overall air quality and optimizing system performance.

Features

✔ Filter Grade: G3, G4 and MERV 7 and 8 to meet specific air quality requirements.

✔ Synthetic Fiber: Made from top-grade synthetic fibers that effectively retain larger particles.

✔ High Dust Capacity: Designed to hold large amounts of dust, ensuring optimal performance.

✔ Energy Efficient: Low airflow resistance reduces energy consumption and operating costs.

✔ Long Life: Sustainable choice that lasts longer with proper cleaning and vacuuming.

✔ Customized: Available in a variety of sizes and thicknesses for different applications.

Air pre-filtration media is an effective solution for improving air quality in your HVAC system, ensuring your environment remains clean and healthy while optimizing the performance of your filtration system. By investing in a high-quality air pre-filter, you can improve indoor air quality, reduce maintenance costs, and increase the overall efficiency of your HVAC system.

Specification

Model	LY-120	LY-150	LY-180	LY-221	LY-250
Material	Polyester
Thickness	5mm	10mm	15mm	20mm	22mm
Initial resistance	20pa	30pa	35pa	35pa	40pa
Final resistance	125pa	200pa	250pa	250pa	250pa
Avg.arrestance(acc.EN779)	68%	83%	86%	89%	92%
Temp.resistance	100°C
Dust holding (tested final)	380g/㎡	450g/㎡	500g/㎡	550g/㎡	580g/㎡
Filtration class	G2	G3	G3	G4	G4
Weight	120	150	180	220	250
Normal size	120m / 220m
Note: other specifications can be customized according to requirements.

Product Display

Frequently Asked Questions

What is the primary function of air pre-filtration media?

It is designed to capture larger dust particles before they reach the main filter, significantly extending the main filter's lifespan and maintaining system efficiency.

Which filter grades are available for this media?

We provide a range of grades including G3, G4, and MERV 7 or 8, allowing you to choose the level of filtration that best suits your specific environment.

Can the size of the filter media be customized?

Yes, while our normal sizes are 1*20m and 2*20m, we can customize dimensions and thicknesses to meet your specific HVAC system requirements.

Is the material resistant to high temperatures?

Yes, our polyester synthetic fiber media features temperature resistance up to 100°C, making it suitable for various industrial applications.

How does it help in reducing operating costs?

By maintaining low initial resistance and providing high dust holding capacity, it minimizes the energy required for airflow and reduces the frequency of expensive main filter replacements.

How do I maintain these pre-filters?

These filters can often last longer with regular maintenance such as vacuuming or gentle cleaning, depending on the specific application and dust loading.
