Discount Activated Carbon Pocket Filter Factories, Quotes

Â Activated Carbon Pocket Filter is a high-performance air filter designed to remove gaseous pollutants, not just particles. Its primary function is the adsorption of odors, volatile organic compounds (VOCs), chemicals, and various gases. It features a robust pocket or bag-style structure, often made from a combination of impregnated carbon fibers and filter cotton, providing a vast surface area for capturing airborne contaminants and ensuring a healthier, more comfortable indoor environment.

Send Inquiry

Product Description

Main Features & Specifications

Primary Function: To adsorb and remove gaseous contaminants like odors, VOCs, chemicals, and fumes from the air.

Core Technology: Uses activated carbon fibers with a rich pore structure and an extremely large surface area, which traps gas molecules.

Construction Details:

Media: Impregnated carbon fibers and filter cotton.
Frame: Options include galvanized steel, stainless steel, or aluminum alloy for durability and corrosion resistance.

Key Performance Traits

• Excellent Adsorption Efficiency: Highly effective at capturing a wide range of gaseous pollutants.

• Low Pressure-Drop & High Dust-Holding: Allows for adequate airflow and can hold a significant amount of particulate matter before needing replacement.

• Strong & Durable: Good mechanical strength and a long service life.

• Efficiency Grade: Typically rated G3/G4, indicating it also provides basic particulate filtration.

How They Work Together

In a comprehensive air filtration system, these filters are often used in sequence for complete air cleaning:

Stage 1: The Paint Booth Intake Filter (G4) acts as a pre-filter to capture large dust and particulate matter.

Stage 2: The Activated Carbon Pocket Filter focuses on adsorbing gases, odors, and VOCs without getting clogged prematurely.

This multi-stage approach ensures high air quality and protects sensitive equipment.

Technical Specifications

Model	LY-HT-3	LY-HT-5	LY-HT-10	LY-HT-15	LY-HT-20
Material	Polyester + Carbon
Thickness	5mm	10mm	15mm	20mm	22mm
Initial resistance	20pa	30pa	35pa	35pa	40pa
Final resistance	125pa	200pa	250pa	250pa	250pa
Avg. arrestance	68%	83%	86%	89%	92%
Temp. resistance	100°C
Dust holding	380g/㎡	450g/㎡	500g/㎡	550g/㎡	580g/㎡
Filtration class	G2	G3	G3	G4	G4
Weight	120	150	180	220	250
Normal size	120m / 220m

Note: Other specifications may be subject to customisation in accordance with customer requirements.

Product Display

Frequently Asked Questions

What is the primary benefit of using activated carbon filters?

The main benefit is the ability to remove gaseous pollutants, VOCs, and unpleasant odors that standard particulate filters cannot capture.

What does the G3/G4 rating signify?

These ratings indicate the filter's efficiency at capturing coarse dust particles according to EN779 standards, providing basic mechanical filtration alongside gas adsorption.

How does the multi-stage filtration process work?

A pre-filter (like G4 intake cotton) captures large dust first, allowing the activated carbon filter to focus purely on chemical and odor removal, extending its lifespan.

Are different frame materials available for these filters?

Yes, depending on your environment, you can choose from galvanized steel, stainless steel, or lightweight aluminum alloy frames.

Can the filter size be customized?

Absolutely. While standard roll sizes are 1x20m and 2x20m, other specifications can be customized to meet specific customer requirements.

What is the maximum temperature resistance?

These filters are designed to withstand temperatures up to 100°C, making them suitable for various industrial applications.
