Application

Washable pre-filters are designed for pre-filtration in a variety of systems, including:

1ã€Air conditioning and ventilation system.

2ã€ Dust removal system.

Send Inquiry

Product Description

Features

1 High Dust Holding Capacity

Effectively captures large amounts of dust and particles, improving overall filtration efficiency.

2 Low Pressure Drop

Maintains optimal airflow with minimal resistance, ensuring energy efficiency of the HVAC system.

3 Washable

Designed to be easy to clean and reuse, reducing waste and operating costs.

4 Sturdy Construction

Built to last, ensuring durability and longevity in various environmental conditions.

5 Beautiful Appearance

Aesthetic design that complements a wide variety of industrial and commercial installations.

Washable pre-filters are an excellent choice for improving the performance of air conditioning and dust collection systems while providing a sustainable and cost-effective filtration solution.

Specification

Model	Size (mm)	CMH (m³/h)	I.N.P (pa)	F.N.P (pa)	Filter Object	EFF (%)	Filtration Class
LY-W-H25	59559525	1700/3400	≤40/80	≤255	≥5μm	95%	G4
	49549525	1200/2400	≤40/80	≤255	≥5μm	95%	G4
	29559525	850/1700	≤40/80	≤255	≥5μm	95%	G4
LY-W-H46	59559546	1200/2400	≤40/80	≤255	≥5μm	95%	G4
	49549546	850/1700	≤40/80	≤255	≥5μm	95%	G4
	29559546	1700/3400	≤40/80	≤255	≥5μm	95%	G4
LY-W-H96	59559596	1700/3400	≤40/80	≤255	≥5μm	95%	G4
	49549596	1200/2400	≤40/80	≤255	≥5μm	95%	G4
	29559596	850/1700	≤40/80	≤255	≥5μm	95%	G4
Note: Special Size Available Upon Request.

Frequently Asked Questions

How often should I wash the pre-filter?

Cleaning frequency depends on your environment's dust levels. Generally, it is recommended to inspect the filter monthly and clean it when dust accumulation is visible or when airflow resistance increases.

What particles does the G4 class filter capture?

The G4 filtration class is designed to capture coarse particles greater than or equal to 5μm, such as lint, hair, and large dust particles.

Is the frame resistant to rust?

Yes, our filters feature sturdy construction designed for durability, often utilizing materials that resist corrosion to ensure a long service life.

Can I order a custom size for my specific HVAC unit?

Absolutely. While we offer standard sizes (25mm, 46mm, 96mm depth), special sizes are available upon request to fit your specific system requirements.

Does this filter help in reducing energy costs?

Yes, the low pressure drop design ensures minimal resistance to airflow, which allows your HVAC fans to operate more efficiently, ultimately reducing energy consumption.

How does "Washable" contribute to sustainability?

Unlike disposable filters, washable pre-filters can be reused many times, significantly reducing landfill waste and the long-term cost of replacement filters.
